• Architectural design LED strip fixture
• Flat & round frosted lens, UGR<22
• Junction box cover included
• CCT and Wattage adjustable
• Steel housing with white powder coat finish
• Celling, wall, or suspension mounting options
|
|
PRODUCT CODE | FINISH | WATTAGE | CCT | IP | BEAM ANGLE | LM | LM/W | DLC 5.1 |
|
|---|---|---|---|---|---|---|---|---|---|---|
|
SNT-SRPWLED15-2FT | White | 15/10/5 | 3500/4000/5000K | IP20 | - |
1950/1965/1980 |
130/131/132 |
Standard/ Premium |
Datasheet |
|
|
SNT-SRPWLED20-2FT |
White |
20/15/10 |
3500/4000/5000K | IP20 | - |
2600/2620/2640 |
130/131/132 |
Standard/ Premium |
Datasheet |
|
|
SNT-SRPWLED25-2FT |
White |
25/20/15 |
3500/4000/5000K | IP20 | - |
3250/3275/3300 |
130/131/132 |
Standard/ Premium |
Datasheet |
|
|
SNT-SRPWLED30-4FT |
White |
30/25/18 |
3500/4000/5000K |
IP20 |
- |
3900/3930/3960 |
130/131/132 |
Standard/ Premium |
Datasheet |
|
|
SNT-SRPWLED35-4FT |
White |
35/30/25 |
3500/4000/5000K |
IP20 |
- |
4550/4585/4620 |
130/131/132 |
Standard/ Premium |
Datasheet |
|
|
SNT-SRPWLED45-4FT |
White |
45/38/34 |
3500/4000/5000K |
IP20 |
- |
5850/5895/5940 |
130/131/132 |
Standard/ Premium |
Datasheet |
|
|
SNT-SRPWLED65- 8FT |
White |
65/55/45 |
3500/4000/5000K |
IP20 |
- |
8450/8515/8580 |
130/131/132 |
Standard/ Premium |
Datasheet |
|
|
SNT-SRPWLED75- 8FT |
White |
75/70/65 |
3500/4000/5000K |
IP20 |
- |
9750/9825/9900 |
130/131/132 |
Standard/ Premium |
Datasheet |
|
|
SNT-SRPWLED90- 8FT |
White |
90/75/65 |
3500/4000/5000K |
IP20 |
- |
11700/11790/11880 |
130/131/132 |
Standard/ Premium |
Datasheet |
|
|
PRODUCT CODE | FUNCTION NAME | DESCRIPTION |
|
|---|---|---|---|---|
 |
ANT-15P | Sensor |
Passive infrared occupancy dual-level sensor that is installed as a fixed sensor on indoor luminaries and provides daylight capture control. All control parameters (hold time, task light level, standby level, standby time) can be adjusted by dip switch, and task light level can also be controlled by remote control. |
Datasheet |
|
MS03B | Sensor |
Moving object sensor with a detection range of 360° and an operating frequency of 5.8GHz. The advantage of the product is that the working state is stable (stable working temperature :-40℃-+70℃). Uses a microwave sensor (high-frequency output <0.2mW), which has better safety performance than infrared sensors. |
Datasheet |
 |
YH28-X | Emergency Pack |
Suit for 8W to 200W lamp with external led driver, |
Datasheet |
