Code: IP20 Batten

IP20 Batten

TZ Series



• PC diffuser, Steel base, Metal gear tray
• Open the luminaire by pushing the catch
• Microwave sensor and emergency kit are on the end of the lamps
• Detachable Terminal Block with Multiple Positions
• Function Options: Microwave Sensor, Emergency Pack, PWM Sensor, DAIL

Contact now Got a question?

TECHNICAL DETAILS


PRODUCT CODE FINISH WATTAGE CCT IP BEAM ANGLE LM LM/W

TZLED106-CCT1

White

10W

4000K

IP20

120°

1280max

120/140/160/180/200

Datasheet

TZLED206-CCT1

White

20W

4000K

IP20

120°

2560max

140/160/180/200LM

Datasheet

TZLED206-CCT3

White

18/15/11/9W

3000/4000/6500K

IP20

120°

2560max

120/140/160/180/200

Datasheet

TZLED112-CCT1

White

20W

4000K

IP20

120°

2560max

120/140/160/180/200

Datasheet

TZLED212-CCT1

White

40W

4000K

IP20

120°

5120max

120/140/160/180/200

Datasheet

TZLED112-CCT3

White

18/15/11/9W

3000/4000/6500K

IP20

120°

2560max

140/160/180/200

Datasheet

TZLED212-CCT3

White

36/30/24/18W

3000/4000/6500K

IP20

120°

5120max

140/160/180/200

Datasheet

TZLED115-CCT1

White

30W

4000K

IP20

120°

3600max

120/140/160/180/200

Datasheet

TZLED215-CCT1

White

60W

4000K

IP20

120°

7200max

120/140/160/180/200

Datasheet

TZLED215-CCT1

White

58W

4000K

IP20

120°

8120max

140/160/180/200

Datasheet

TZLED115-CCT3

White

23/19/15/12W

3000/4000/6500K

IP20

120°

3240max

140/160/180/200

Datasheet

TZLED215-CCT3

White

46/38/30/24W

3000/4000/6500K

IP20

120°

6480max

140/160/180/200

Datasheet

TZLED215-CCT3

White

58/49/40/31W

3000/4000/6500K

IP20

120°

8120max

140/160/180/200

Datasheet

TZLED118-CCT1

White

40W

4000K

IP20

120°

4860max

120/140/160/180/200

Datasheet

TZLED218-CCT1

White

80W

4000K

IP20

120°

9600max

120/140/160/180/200

Datasheet

TZLED118-CCT3

White

34/29/24/19W

3000/4000/6500K

IP20

120°

4860max

140/160/180/200

Datasheet

TZLED218-CCT3

White

68/58/48/38W

3000/4000/6500K

IP20

120°

9720max

140/160/180/200

Datasheet


Functional options


PRODUCT CODE FUNCTION NAME DESCRIPTION

BVP--Athena Sensor DC Input,DIP switch
Detection distance 6-12m
On-off sensing and 3 levels of dimming control optional
Datasheet

BVP--Medusa Emergency kit Integral Emergency Kit
3 hours emergency working time
Easy to replace lithium iron phosphate battery pack
Manual quick function test button
Datasheet
